Rozměr
|
HKP/L
4kN/8kN/12kN
|
HKP/L
13kN/20kN
|
HKP/L
33kN/45kN/56kN
|
|
|
|
A
|
310
|
420
|
520
|
|
|
|
B
|
100
|
130
|
185
|
|
|
|
C
|
415
|
590
|
715
|
|
|
|
D
|
200
|
300
|
340
|
|
|
|
D1
|
20
|
30
|
30
|
|
|
|
E
|
120
|
160
|
200
|
|
|
|
F
|
93
|
130
|
150
|
|
|
|
G
|
75
|
100
|
120
|
|
|
|
H
|
/
|
100
|
100
|
|
|
|
I
|
10
|
10
|
12
|
|
|
|
J
|
40
|
80
|
80
|
|
|
|
K
|
40
|
60
|
60
|
|
|
|
L
|
90
|
120
|
165
|
|
|
|
M
|
140
|
160
|
215
|
|
|
|
N
|
140
|
160
|
200
|
|
|
|
O
|
120
|
130
|
160
|
|
|
|
P
|
120
|
144
|
195
|
|
|
|
Q
|
Ř9
|
Ř9
|
Ř11
|
|
|
|
R
|
308/343/378
|
440/477
|
545/580/620
|
|
|
|
S
|
975
|
450
|
570
|
|
|
|
T
|
48
|
65
|
90
|
|
|
|
U
|
21
|
29
|
49
|
|
|
|
V
|
Ř10 H7
|
Ř15 H7
|
Ř25 H7
|
|
|
|
W
|
33
|
48
|
55
|
|
|
|
X
|
73-240
|
100-320
|
110-375
|
|
|
|
X1
|
6-46
|
6-58
|
6-59
|
|
|
|
Y max.
|
650/685/720
|
940
|
1245
|
|
|
|
Z
|
72
|
125
|
160
|
|
|
|
Provozní tlak:
|
2-7 bar
|
2-7 bar
|
2-6 bar
|
|
|
|
Lisovací síla kN
při X barech cca
|
4/8/12
7 bar
|
13/20
7 bar
|
33/45/56
6 bar
|
|
|
|
Spotřeba vzduchu
max. na jeden zdvih
|
0,07/0,11/0,14
L x bar
|
0,19/0,25
L x bar
|
0,45/0,56/0,67
L x bar
|
|
|
|
Pneum. přípojné vedení
|
1/4"
|
1/4"
|
1/2"
|
|
|
|
Váha
|
36,5 kg
|
87,5 kg
|
193 kg
|
|
|
|
|
|
|
